Stryker Prime Series Stretcher

The Stryker Prime Series is designed to usher in a new era of patient care by prioritizing both clinician safety and patient comfort. Engineered to reduce physical strain on care teams, the Prime Series offers advanced mobility options like Big Wheel and Zoom motorized drive, making transport smoother and easier. With the introduction of Prime Connect, this system evolves into a smart, connected stretcher that assists with fall protocol compliance from anywhere in the facility.

Key Features and Benefits

• Advanced Mobility Options: The Big Wheel system reduces start-up push force and steering effort, while the Zoom motorized drive helps decrease manual pushing requirements entirely.
• Prime Connect™ Technology: A smart footboard system that includes bed exit controls, visual status lights, an integrated scale, and wireless capabilities to help enable fall protocol compliance.
• Electric-Powered Lift Pedal: Eliminates repetitive manual pumping by allowing staff to raise the litter with a simple hydraulic pedal, providing quick access to the patient.
• Lift Assist Backrest: Uses the patient’s own weight to help raise the head of the stretcher, while the drop seat design minimizes the need for boosting patients up the mattress.
• Recovery Chair Position: Allows the stretcher to articulate into a comfortable seated position, helping to eliminate unnecessary patient transfers.
• IsoFlex® SE Support Surface: Offers pressure redistribution and comfort to aid in the treatment and prevention of pressure injuries.
• High Weight Capacity: Supports a safe working load of up to 700 lbs (318 kg) to accommodate a diverse patient population.
• Power-Washable Design: The frame allows for power washing, facilitating easier cleaning and infection control.

Model Configurations

• Model 1105: Features Fifth Wheel mobility for improved steering and control.
• Model 1115: Features Big Wheel advanced mobility for reduced push force.
• Model 1125: Features Zoom motorized drive system for powered transport assistance.

Specifications

• Patient Surface Widths: Available in 26″ (66 cm) and 30″ (76 cm) options.
• Overall Length: 85″ (215.9 cm) for models 1105/1115; 86″ (218.4 cm) for model 1125.
• Height Range (High): 34″ (86.4 cm).
• Height Range (Low): 20.75″ (52.7 cm) for models 1105/1115; 23″ (58 cm) for model 1125.
• Weight Capacity: 700 lbs (318 kg).
• Backrest Positioning: 0° to 90°.
• Trendelenburg/Reverse Trendelenburg: +17°/-17° (Models 1105/1115); +17°/-16° (Model 1125).
• Siderails: 14″ x 57.75″ (36 x 147 cm).
• Casters: 8″ (20 cm).
• Electric Functionality: Available in 120V or 240V (30-inch model only).

Clinical Applications

The Stryker Prime Series is versatile enough for use throughout the hospital environment:

• Emergency Department: Rapid transport capabilities and rugged design allow for efficient patient movement in high-acuity situations.
• PACU and Recovery: The recovery chair position helps eliminate the need for unnecessary transfers by providing a comfortable seated position.
• Medical-Surgical Units: Prime Connect features assist nursing staff in monitoring fall risks with bed exit controls and integrated scales.

Why Choose the Stryker Prime Series?

The Stryker Prime Series represents the intersection of durability, mobility, and technology. By offering features like Zoom motorized drive and the Lift Assist backrest, it directly addresses the leading causes of nurse injury—pushing heavy loads and repositioning patients. With the addition of Prime Connect, facility managers gain new tools for safety compliance, making this stretcher a comprehensive solution for modern healthcare demands.

Heartland Medical Support and Service

Heartland Medical’s dedicated support professionals are committed to enhancing patient care while protecting your investment. Our field service engineers and in-house technical experts are available 24 hours a day, 7 days a week for preventive maintenance, troubleshooting, and parts support. Contact Heartland Medical Sales & Services today for additional information or to request a free quote on the Stryker Prime Series Stretcher.
